Triton TWX7CS001 Contractor Saw Module (DISCONTINUED)

Triton TWX7CS001 Contractor Saw Module (DISCONTINUED)

Incl. VAT

SKU: TRITWX7CS001-DISCON Category: Table Saws

Product Description

Precision contractor saw module designed for use with the Workcentre TWX7, resulting in a full-featured saw table capable of professional results. Powerful 1800W motor and precision 254mm TCT blade. Accurate 86mm blade height adjustment and 0-45° bevel angle adjustment for performing complex bevel cuts. Protractor gauge and rip fence for performing rip cuts, cross cuts and mitre cuts. Dust extraction port located below the table surface for efficient, unobtrusive dust removal. Easy to assemble and configure and fully supported by optional accessories for extending functionality.

Features:

Powerful 1800W motor and precision 254mm TCT blade easily performs a multitude of sawing tasks
Includes protractor gauge for precise cross cutting and mitre cutting
Rip fence with built in T-slot for precision rip cuts and accessory support
Dual dust extraction ports for cleaner safer operation
Table surface hand slots for ease of module removal
Adjustable bevel angle for precise 0-45° bevel cuts
Includes push-stick for safe control of the workpiece near the blade

Downloads:

TWX7 CS001 – Instruction Manual
TWX7 CS001 – Schematic Diagram
TWX7 CS001 – Product Sheet

Technical Data:

Bevel Range: 0-45°
Blade Diameter: 254mm
Blade Type: 40TCT
Bore Diameter: Blade – 30mm
Cut Capacity – 45°: 59.5mm
Cut Capacity – 90°: 86mm
Cut Capacity – Rip: 775mm
No Load Speed: 4500rpm
Power: 1800W
Product Weight: 14.66kg
Standard: ATB EN847 – 1 Compliant
Table Height: 290mm
Table Size: 660 x 410 mm
